Cairon C 2.0 B RBN wave
4,299.95€ *
E-SUV ➜ Material: Aluminium ✓ Farbe: grau ✓ Gewicht: 28,50 kg ✓ Laufradgröße: 27" ✓ Gänge: 5-Gang ✓ Antriebsvariante: Mittelmotor ✓ ➤ Jetzt entdecken
Product information
"Cairon C 2.0 B RBN wave "
Do you fancy an active and sporty lifestyle? With our "Cairon C 2.0 RBN" you get exactly that! The Bosch mid-motor with 800 Wh Battery provides you with powerful support, while the low-maintenance belt drive and Shimano "Hub" 5-speed hub ensure a smooth, clean ride. In addition, the coaster brake hub offers you a familiar plus in safety and comfort - especially in city traffic.
Bumps in the forest or cobblestones? The 29" wheels and 120 mm Suspension Fork simply bar them away. The frame geometry puts you in a dynamic but relaxed riding position - with efficient pedaling, a good overview and stable control. This is ensured by the balanced tube length distribution and the well thought-out angle design. Even when riding fast or fully loaded, the bike remains confident and directionally stable.
Practical: the Battery can be easily removed from the top. With the HTM 2.0 front carrier mount, BCM module and Range Extender ready, you are flexible for touring, commuting or shopping. A real SUV bike for anyone who wants to live an active life - without compromise.
Bumps in the forest or cobblestones? The 29" wheels and 120 mm Suspension Fork simply bar them away. The frame geometry puts you in a dynamic but relaxed riding position - with efficient pedaling, a good overview and stable control. This is ensured by the balanced tube length distribution and the well thought-out angle design. Even when riding fast or fully loaded, the bike remains confident and directionally stable.
Practical: the Battery can be easily removed from the top. With the HTM 2.0 front carrier mount, BCM module and Range Extender ready, you are flexible for touring, commuting or shopping. A real SUV bike for anyone who wants to live an active life - without compromise.
Spezifikationen
| Frame: | CONWAY Intube Bosch, Alu |
| Dropout: | 0347028/3 |
| Fork: | SUNTOUR "XCM34 LOR", Boost, 120 mm |
| Headset: | ACROS "ZS56-ZS56", Blocklock |
| Crank arm: | MIRANDA "Virage", Q12, 165mm |
| Chain ring / belt ring: | GATES "CDX w Guard", 46 Z. |
| Bottom Bracket: | BOSCH |
| Brakes: | TEKTRO "HD-M280" |
| Brake lever: | TEKTRO "HD-M280" |
| Front rotor: | TEKTRO "TR180-35", 180 mm |
| Rear rotor: | TEKTRO "TR180-35", 180 mm |
| Shifting lever: | SHIMANO "NexusSL-C7000-5" |
| Rear derailleur: | SHIMANO "NexusSG-C7000-5CD", 5-speed |
| Cassette / belt sprocket: | GATES "CDX", 32 Z. |
| Chain / belt: | GATES "CDX Belt", 125 Z. |
| Drive unit: | BOSCH Mittelmotor "Performance PX", 36 V, 250 W |
| Battery: | BOSCH "Powertube 800", Lithium-Ionen mit BMS, HOR w. SOP Pivot |
| Charger: | Bosch 2 A, BES3 |
| Remote: | BOSCH "LED Remote" |
| Display: | BOSCH "Kiox 300" |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | CONWAY "TRYP 30" |
| Spokes: | Niro |
| Front hub: | SHIMANO "HB-TC500", 15 x 110 mm |
| Rear hub: | SHIMANO "NexusSG-C7000-5CD" |
| Front tires: | SCHWALBE "Smart Sam", 60-584 |
| Rear tires: | SCHWALBE "Smart Sam", 60-584 |
| Handle bar: | SATORI "Noir", 15° backsweep, 660 mm |
| Stem: | SATORI "Hatchback adjustable", 70mm |
| Grips: | CONTEC "Tour Wing" |
| Saddle: | SELLE ROYAL "Vivo Moderat Ergo" |
| Seat post: | LIMOTEC "D1", 31,6 mm, 75 mm |
| Mud Guards: | CURANA "Apollo 75" |
| Carrier: | MASSLOAD "MIK HD", inkl. Federklappe |
| Front light: | HERRMANS "MR5" |
| Tail light: | AXA "Juno E-Bike", Brake Light |
| Kickstand: | URSUS "MOOI Plus", 40 mm |
| Pedals: | VP "VPE-527" |
Technical data
| Category: | SUV |
| E-bike: | yes |
| Bosch Smart System: | yes |
| Drive system: | BOSCH Performance Line PX |
| Drive version: | middle motor |
| Battery capacity: | 800 Wh |
| Support: | till 25km/h |
| Sex: | ladies |
| Frame shape: | wave |
| Frame size: | S |
| Frame height: | 41 cm |
| Wheel size: | 27" |
| Shifting type: | hub gear |
| Gears: | 5-speed |
| Transmission: | 1x_5-fach |
| Circuit brand: | Shimano |
| Shifting model: | Nexus |
| Brake system: | hydraulic disc brake |
| Travel: | 120 mm |
| Features: | suspension fork, electronic sliding aid, fender |
| Zulässiges Systemgewicht: | 140 kg |
| Material: | aluminium |
| Colour: | grey |
| Colour designation: | anthracite matt |
| Weight: | 28,50 kg |
| EAN | 4251971177666 |
Geometry data
S
M
L
XL
| A - Seat tube: | 410 mm |
| B - Toptube: | 585 mm |
| C - Steering tube angle: | 67° |
| D - Stem length: | 60 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 466 mm |
| G - Steering tube: | 155 mm |
| H - Reach: | 400 mm |
| I - Stack: | 667 mm |
| J - Wheel distance: | 1.168 mm |
| A - Seat tube: | 450 mm |
| B - Toptube: | 600 mm |
| C - Steering tube angle: | 68° |
| D - Stem length: | 80 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 466 mm |
| G - Steering tube: | 160 mm |
| H - Reach: | 413 mm |
| I - Stack: | 674 mm |
| J - Wheel distance: | 1.177 mm |
| A - Seat tube: | 490 mm |
| B - Toptube: | 620 mm |
| C - Steering tube angle: | 68° |
| D - Stem length: | 80 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 466 mm |
| G - Steering tube: | 170 mm |
| H - Reach: | 429 mm |
| I - Stack: | 686 mm |
| J - Wheel distance: | 1.192 mm |
| A - Seat tube: | 530 mm |
| B - Toptube: | 640 mm |
| C - Steering tube angle: | 68° |
| D - Stem length: | 100 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 466 mm |
| G - Steering tube: | 180 mm |
| H - Reach: | 447 mm |
| I - Stack: | 695 mm |
| J - Wheel distance: | 1.213 mm |
| S | M | L | XL | |
|---|---|---|---|---|
| A - Seat tube: | 410 mm | 450 mm | 490 mm | 530 mm |
| B - Toptube: | 585 mm | 600 mm | 620 mm | 640 mm |
| C - Steering tube angle: | 67° | 68° | 68° | 68° |
| D - Stem length: | 60 mm | 80 mm | 80 mm | 100 mm |
| E - Seat angle: | 75° | 75° | 75° | 75° |
| F - Kettenstrebe: | 466 mm | 466 mm | 466 mm | 466 mm |
| G - Steering tube: | 155 mm | 160 mm | 170 mm | 180 mm |
| H - Reach: | 400 mm | 413 mm | 429 mm | 447 mm |
| I - Stack: | 667 mm | 674 mm | 686 mm | 695 mm |
| J - Wheel distance: | 1.168 mm | 1.177 mm | 1.192 mm | 1.213 mm |
