Product information
"Cairon S 6.0 Hardtail, trapeze "
The "Cairon S 6.0" is a new addition to the "Cairon" family from CONWAY. Equipped with a full 750 Wh Battery and the sporty BOSCH "Performance CX" engine and SRAM "NX Eagle" derailleur gears, it is a wonderful addition to the portfolio. The frame of the e-hardtail is designed to accommodate the "PowerTube" Battery completely in the down tube, giving the bike a tidy and clean appearance.
The "NX Eagle" groupset is a performance driver at a fair price. It also impresses with quiet and precise shifting thanks to its 11-50 teeth. This makes it ideal for tours into the low mountain ranges and always ensures the right cadence even on steep climbs. The 29er wheels impress with the best rollover characteristics.
The bike also scores points with its stable straight-line stability, the 120 mm travel of the ROCKSHOX "Recon Silver RL" air Suspension Fork and the 65 mm wide "Johnny Watts" tires from SCHWALBE. The "Cairon S 6.0" features hydraulic disc brakes from SHIMANO for superior deceleration. Their power can be precisely controlled, but they also pack a punch when needed. The disk diameter is 180 mm at the front and rear.
The overall low center of gravity, which is ensured by the placement of the engine and batteries, makes riding this e-MTB natural and balanced. The Battery has sufficient capacity in any case. And if not - it can either be removed from the bottom of the frame for charging, or you can use the Charging Socket on the side if you want to charge it quickly and easily during a break.
The "NX Eagle" groupset is a performance driver at a fair price. It also impresses with quiet and precise shifting thanks to its 11-50 teeth. This makes it ideal for tours into the low mountain ranges and always ensures the right cadence even on steep climbs. The 29er wheels impress with the best rollover characteristics.
The bike also scores points with its stable straight-line stability, the 120 mm travel of the ROCKSHOX "Recon Silver RL" air Suspension Fork and the 65 mm wide "Johnny Watts" tires from SCHWALBE. The "Cairon S 6.0" features hydraulic disc brakes from SHIMANO for superior deceleration. Their power can be precisely controlled, but they also pack a punch when needed. The disk diameter is 180 mm at the front and rear.
The overall low center of gravity, which is ensured by the placement of the engine and batteries, makes riding this e-MTB natural and balanced. The Battery has sufficient capacity in any case. And if not - it can either be removed from the bottom of the frame for charging, or you can use the Charging Socket on the side if you want to charge it quickly and easily during a break.
Spezifikationen
| Frame: | Intube Bosch, Gen. 4, BES3, aluminum, trapeze, 41 cm |
| Dropout: | CONWAY for WME Carbon, Xyron, RLC FS, Cairon SUV FS, from mod. 2020 |
| Fork: | ROCKSHOX "Recon Silver RL", 120 mm travel, SoloAir, Motion Control, Maxle Lite Thru Axle |
| Headset: | ACROS ZS56/28.6 / ZS56/40, 120° blocklock |
| Crank set: | MIRANDA "Classic", 170 mm, 36 teeth |
| Bremse V.R.: | SHIMANO "Deore BL-M4100 / BR-MT420", Post Mount |
| Bremse H.R.: | SHIMANO "BL-M4100 / BR-MT410" |
| Front rotor: | SHIMANO "SM-RT54", Ø 180 mm, Center Lock |
| Rear rotor: | SHIMANO "SM-RT54", Ø 180 mm, Center Lock |
| Shifting lever: | SRAM "SX Eagle" |
| Rear derailleur: | SRAM "NX Eagle" |
| Cassette / belt sprocket: | SRAM "PG-1230", 11-50 teeth |
| Chain / belt: | SRAM "SX Eagle" |
| Drive unit: | BOSCH "Performance Line CX", max. 85 Nm |
| Battery: | BOSCH "PowerTube 750", 750 Wh |
| Charger: | BOSCH 4 A |
| Remote: | BOSCH "BRC3600", LED Remote |
| Display: | BOSCH "Kiox 300", 4-stages, remote control, push aid |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | CROSS "X18", 32 hole, eyeleted |
| Spokes: | Niro, schwarz |
| Front hub: | PROMAX "DR850F", 15 x 110 mm Boost, Thru Axle, Center Lock |
| Rear hub: | SHIMANO "Alivio FH-MT400-B", 12 x 148 mm Boost, Center Lock, Thru Axle |
| Front tires: | SCHWALBE "Johnny Watts", 65-622, Reflex |
| Rear tires: | SCHWALBE "Johnny Watts", 65-622, Reflex |
| Handle bar: | LEVELNINE "Race Riser", 780 mm, Ø 31.8 mm, Backsweep 9°, Rise 15 mm |
| Stem: | LEVELNINE "Team A-Head", 1 1/8", 31,8mm handlebar clamp, 40mm long, black |
| Grips: | SQlab "70X" |
| Saddle: | Selle Royal "Vivo", Athletic |
| Seat post: | CONWAY, Ø 27.2 mm, 350 mm long, 10 mm offset |
| Battery Lock: | AXA "New Lock" |
| Pedals: | VP COMPONENTS "VPE-506" |
Technical data
| Category: | Hardtail |
| E-bike: | yes |
| Bosch Smart System: | yes |
| Drive system: | BOSCH Performance Line CX |
| Drive version: | middle motor |
| Battery capacity: | 750 Wh |
| Support: | till 25km/h |
| Sex: | ladies |
| Frame shape: | trapeze |
| Frame size: | S |
| Frame height: | 41 cm |
| Wheel size: | 29" |
| Shifting type: | derailleur |
| Gears: | 12-speed |
| Transmission: | 1x 12-fach |
| Circuit brand: | SRAM |
| Shifting model: | NX |
| Brake system: | hydraulic disc brake |
| Travel: | 120 mm |
| Features: | suspension fork, electronic sliding aid |
| Zulässiges Systemgewicht: | 130 kg |
| Material: | aluminium |
| Colour: | grey |
| Colour designation: | red metallic / shadowgrey metallic |
| Weight: | 25,60 kg |
| EAN | 4251507981019 |
Geometry data
S
M
L
XL
| A - Seat tube: | 410 mm |
| B - Toptube: | 585 mm |
| C - Steering tube angle: | 67° |
| D - Stem length: | 40 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 455 mm |
| G - Steering tube: | 120 mm |
| H - Reach: | 409 mm |
| I - Stack: | 647 mm |
| J - Wheel distance: | 1.162 mm |
| A - Seat tube: | 450 mm |
| B - Toptube: | 600 mm |
| C - Steering tube angle: | 67° |
| D - Stem length: | 40 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 455 mm |
| G - Steering tube: | 120 mm |
| H - Reach: | 426 mm |
| I - Stack: | 649 mm |
| J - Wheel distance: | 1.174 mm |
| A - Seat tube: | 490 mm |
| B - Toptube: | 620 mm |
| C - Steering tube angle: | 67° |
| D - Stem length: | 40 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 455 mm |
| G - Steering tube: | 130 mm |
| H - Reach: | 445 mm |
| I - Stack: | 658 mm |
| J - Wheel distance: | 1.197 mm |
| A - Seat tube: | 530 mm |
| B - Toptube: | 640 mm |
| C - Steering tube angle: | 67° |
| D - Stem length: | 40 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 455 mm |
| G - Steering tube: | 130 mm |
| H - Reach: | 468 mm |
| I - Stack: | 658 mm |
| J - Wheel distance: | 1.220 mm |
| S | M | L | XL | |
|---|---|---|---|---|
| A - Seat tube: | 410 mm | 450 mm | 490 mm | 530 mm |
| B - Toptube: | 585 mm | 600 mm | 620 mm | 640 mm |
| C - Steering tube angle: | 67° | 67° | 67° | 67° |
| D - Stem length: | 40 mm | 40 mm | 40 mm | 40 mm |
| E - Seat angle: | 75° | 75° | 75° | 75° |
| F - Kettenstrebe: | 455 mm | 455 mm | 455 mm | 455 mm |
| G - Steering tube: | 120 mm | 120 mm | 130 mm | 130 mm |
| H - Reach: | 409 mm | 426 mm | 445 mm | 468 mm |
| I - Stack: | 647 mm | 649 mm | 658 mm | 658 mm |
| J - Wheel distance: | 1.162 mm | 1.174 mm | 1.197 mm | 1.220 mm |
