Nyvo 2.0 C diamond
1,699.95€ *
GRAVEL ➜ Material: aluminium ✓ Colour: gold ✓ Weight: 12,30 kg ✓ Wheel size: 28" ✓ Brake system: hydraulic disc brake ✓ Gears: 20-speed ✓ ➤ Discover now
Product information
"Nyvo 2.0 C diamond "
The "Nyvo 2.0 C" is your entry into the gravel world - clean in look, versatile in use and equipped with everything you need for everyday use: Fenders, Carrier and a permanently installed lighting system make the bike suitable for commuting without losing its sporty character. The geometry gives you a balanced, slightly stretched riding position that combines efficient pedaling with comfortable control. Thanks to the long wheelbase and short Chain Stays, the bike remains both directional and agile, even on changing surfaces.
The Shimano 2x10-speed gearing gives you enough range for steep climbs and fast passages, while the hydraulic Disc Brakes give you reliable control in all weathers. The aluminum frame is robust, offers plenty of mounting points for bags and accessories and is designed for wide tires. Fully integrated cables and a hidden neoprene bag in the frame compartment round off the minimalist design.
The Shimano 2x10-speed gearing gives you enough range for steep climbs and fast passages, while the hydraulic Disc Brakes give you reliable control in all weathers. The aluminum frame is robust, offers plenty of mounting points for bags and accessories and is designed for wide tires. Fully integrated cables and a hidden neoprene bag in the frame compartment round off the minimalist design.
Spezifikationen
| Frame: | CONWAY Gravel, Alu |
| Dropout: | 0347028/3 |
| Fork: | Gravel "Carbon/Carbon" |
| Headset: | ACROS "IS52 / IS52 ICR" |
| Crank set: | SHIMANO "Cues FC-U6030-2", 165 mm |
| Bottom Bracket: | SHIMANO "PF BB-RS500" |
| Brakes: | SHIMANO "Cues U6030" |
| Brake lever: | SHIMANO "Cues U6030" |
| Front rotor: | SHIMANO "SM-RT54", 160 mm |
| Rear rotor: | SHIMANO "SM-RT54", 160 mm |
| Shifting lever: | SHIMANO "Cues U6030" |
| Front derailleur: | SHIMANO "Cues FD-U6030" |
| Rear derailleur: | SHIMANO "Cues RD-U6020", 10speed |
| Cassette / belt sprocket: | SHIMANO "CS-LG400-10", 11-39 Z. |
| Chain / belt: | SHIMANO "CN-LG500" |
| Rims: | RODI "Sniper" |
| Spokes: | Niro |
| Front hub: | SHIMANO "DH-UR705-3D", 12 x 100 mm |
| Rear hub: | SHIMANO "FH-TC500", 12 x 142 mm |
| Front tires: | MAXXIS "Rambler", 40-622 |
| Rear tires: | MAXXIS "Rambler", 40-622 |
| Handle bar: | JD "Gravel Alloy Light", 400mm |
| Stem: | JD "Road Alloy Light", ICR, 80mm |
| Grips: | VELO "VLT-1051 black" |
| Saddle: | SELLE ROYAL "SRX" |
| Seat post: | JD "Two Piece Alloy", 27,2 mm, 350 mm |
| Mud Guards: | CURANA "C-Lite 50" |
| Carrier: | ATRAN "Urban Light" |
| Front light: | HERRMANS "MR5" |
| Tail light: | AXA "Juno", Batt. Light |
Technical data
| Category: | Gravel Bike |
| E-bike: | no |
| Sex: | gents |
| Frame shape: | diamond |
| Frame size: | S |
| Frame height: | 48 cm |
| Wheel size: | 28" |
| Shifting type: | derailleur |
| Gears: | 20-speed |
| Transmission: | 2x 10-fach |
| Circuit brand: | Shimano |
| Shifting model: | Cues |
| Brake system: | hydraulic disc brake |
| Zulässiges Systemgewicht: | 130 kg |
| Material: | aluminium |
| Colour: | gold |
| Colour designation: | bronze matt |
| Weight: | 12,30 kg |
| EAN | 4251971177130 |
Geometry data
S
M
L
XL
| A - Seat tube: | 480 mm |
| B - Toptube: | 535 mm |
| C - Steering tube angle: | 70° |
| D - Stem length: | 80 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 435 mm |
| G - Steering tube: | 115 mm |
| H - Reach: | 380 mm |
| I - Stack: | 554 mm |
| J - Wheel distance: | 1.039 mm |
| A - Seat tube: | 510 mm |
| B - Toptube: | 555 mm |
| C - Steering tube angle: | 70° |
| D - Stem length: | 80 mm |
| E - Seat angle: | 75° |
| F - Kettenstrebe: | 435 mm |
| G - Steering tube: | 130 mm |
| H - Reach: | 396 mm |
| I - Stack: | 568 mm |
| J - Wheel distance: | 1.060 mm |
| A - Seat tube: | 540 mm |
| B - Toptube: | 575 mm |
| C - Steering tube angle: | 71° |
| D - Stem length: | 90 mm |
| E - Seat angle: | 74° |
| F - Kettenstrebe: | 435 mm |
| G - Steering tube: | 155 mm |
| H - Reach: | 405 mm |
| I - Stack: | 593 mm |
| J - Wheel distance: | 1.073 mm |
| A - Seat tube: | 570 mm |
| B - Toptube: | 595 mm |
| C - Steering tube angle: | 71° |
| D - Stem length: | 100 mm |
| E - Seat angle: | 74° |
| F - Kettenstrebe: | 435 mm |
| G - Steering tube: | 175 mm |
| H - Reach: | 420 mm |
| I - Stack: | 612 mm |
| J - Wheel distance: | 1.094 mm |
| S | M | L | XL | |
|---|---|---|---|---|
| A - Seat tube: | 480 mm | 510 mm | 540 mm | 570 mm |
| B - Toptube: | 535 mm | 555 mm | 575 mm | 595 mm |
| C - Steering tube angle: | 70° | 70° | 71° | 71° |
| D - Stem length: | 80 mm | 80 mm | 90 mm | 100 mm |
| E - Seat angle: | 75° | 75° | 74° | 74° |
| F - Kettenstrebe: | 435 mm | 435 mm | 435 mm | 435 mm |
| G - Steering tube: | 115 mm | 130 mm | 155 mm | 175 mm |
| H - Reach: | 380 mm | 396 mm | 405 mm | 420 mm |
| I - Stack: | 554 mm | 568 mm | 593 mm | 612 mm |
| J - Wheel distance: | 1.039 mm | 1.060 mm | 1.073 mm | 1.094 mm |
