Cairon T 100 500 trekking bike, diamond
2,599.95€ *
E-BIKES ➜ Material: aluminium ✓ Weight: 27,20 kg ✓ Wheel size: 28" ✓ Brake system: hydraulic disc brake ✓ Permissible total weight: 130 kg ✓ ➤ Discover now
E-BIKES ➜ Material: aluminium ✓ Weight: 27,20 kg ✓ Wheel size: 28" ✓ Brake system: hydraulic disc brake ✓ Permissible total weight: 130 kg ✓ ➤ Discover now
| Frame: | CONWAY Bosch, Alu |
| Dropout: | 0281167/7 |
| Fork: | RST "Blaze T", 80 mm |
| Headset: | ZS44 / ZS56, Reduzierkonus |
| Crank arm: | FSA "CK-200", 170 mm |
| Chain ring / belt ring: | FSA "WB385 W1144", 38 Z. |
| Bottom Bracket: | BOSCH |
| Brakes: | SHIMANO "BR-MT200" |
| Brake lever: | SHIMANO "BL-MT200" |
| Front rotor: | SHIMANO "SM-RT30", 180 mm |
| Rear rotor: | SHIMANO "SM-RT30", 180 mm |
| Shifting lever: | SHIMANO "Altus SL-M2000" |
| Rear derailleur: | SHIMANO "Altus RD-M2000", 9speed |
| Cassette / belt sprocket: | SHIMANO "HG200", 11-36 Z. |
| Chain / belt: | SHIMANO "HG53" |
| Drive unit: | BOSCH Mittelmotor Gen.3 "Performance", 36 V, 250 W |
| Battery: | BOSCH "Powerpack 500", Lithium-Ionen mit BMS, 500 Wh |
| Charger: | Bosch 2 Ah |
| Display: | BOSCH, "Intuvia " 4-Stufen, Remote Control, Schiebehilfe |
| Sensor: | Tretkraftmessung im Motor + Geschwindigkeitssensor |
| Rims: | CONWAY Hohlkammer "X6", Disc |
| Spokes: | Niro |
| Front hub: | SHIMANO "HB-TX505" QR |
| Rear hub: | SHIMANO "FH-TX505" QR |
| Front tires: | SCHWALBE "Energizer Active Plus", 50-622, Reflex |
| Rear tires: | SCHWALBE "Energizer Active Plus", 50-622, Reflex |
| Handle bar: | ERGOTEC "Low Riser", Ø 31,8, 720 mm |
| Stem: | ERGOTEC "Octopus", Adjustable |
| Grips: | CONWAY "Sport" |
| Saddle: | SELLE ROYAL "Vivo Athletic Ergo", He |
| Seat post: | CONWAY Patent, 31,6 mm |
| Chain guard: | Wave = HESLING "Move" |
| Mud Guards: | SKS, Kunststoff |
| Carrier: | ATRAN "Cummute Pro", inkl. Federklappe |
| Front light: | HERRMANS "MR GO 30", E-bike |
| Tail light: | AXA "Blueline", LED |
| Frame Lock: | AXA "Bock XXL" |
| Kickstand: | URSUS, Alu |
| Pedals: | Marwie "SP 827" |
| Category: | trekking bike |
| E-bike: | yes |
| Bosch Smart System: | no |
| Drive system: | Bosch |
| Drive version: | middle motor |
| Battery capacity: | 500 Wh |
| Support: | till 25km/h |
| Sex: | gents |
| Frame shape: | diamond |
| Frame size: | S |
| Frame height: | 46 cm |
| Wheel size: | 28" |
| Drive: | chain drive |
| Shifting type: | derailleur |
| Gears: | 9-speed |
| Transmission: | 1x 9-fach |
| Circuit brand: | Shimano |
| Shifting model: | Acera |
| Brake system: | hydraulic disc brake |
| Travel: | 80 mm |
| Features: | suspension fork, suspensed seat post, chain guard, electronic sliding aid, fender |
| Permissible total weight: | 130 kg |
| Material: | aluminium |
| Type: | Article |
| Colour: | black, orange |
| Colour designation: | black / grey orange |
| EAN | 4251507961110 |
| A - Seat tube: | 460 mm |
| B - Toptube: | 570 mm |
| C - Steering tube angle: | 70° |
| D - Seat angle: | 73° |
| E - Kettenstrebe: | 485 mm |
| F - Steering tube: | 130 mm |
| G - Stack: | 628 mm |
| H - Wheel distance: | 1.123 mm |
| A - Seat tube: | 500 mm |
| B - Toptube: | 585 mm |
| C - Steering tube angle: | 71° |
| D - Seat angle: | 73° |
| E - Kettenstrebe: | 485 mm |
| F - Steering tube: | 130 mm |
| G - Stack: | 630 mm |
| H - Wheel distance: | 1.132 mm |
| A - Seat tube: | 540 mm |
| B - Toptube: | 600 mm |
| C - Steering tube angle: | 71° |
| D - Seat angle: | 73° |
| E - Kettenstrebe: | 485 mm |
| F - Steering tube: | 150 mm |
| G - Stack: | 651 mm |
| H - Wheel distance: | 1.142 mm |
| A - Seat tube: | 580 mm |
| B - Toptube: | 615 mm |
| C - Steering tube angle: | 71° |
| D - Seat angle: | 73° |
| E - Kettenstrebe: | 485 mm |
| F - Steering tube: | 150 mm |
| G - Stack: | 651 mm |
| H - Wheel distance: | 1.157 mm |
| S | M | L | XL | |
|---|---|---|---|---|
| A - Seat tube: | 460 mm | 500 mm | 540 mm | 580 mm |
| B - Toptube: | 570 mm | 585 mm | 600 mm | 615 mm |
| C - Steering tube angle: | 70° | 71° | 71° | 71° |
| D - Seat angle: | 73° | 73° | 73° | 73° |
| E - Kettenstrebe: | 485 mm | 485 mm | 485 mm | 485 mm |
| F - Steering tube: | 130 mm | 130 mm | 150 mm | 150 mm |
| G - Stack: | 628 mm | 630 mm | 651 mm | 651 mm |
| H - Wheel distance: | 1.123 mm | 1.132 mm | 1.142 mm | 1.157 mm |
